Allright, results are in and disappointing: same results as with the 2 ltr set-up!
235 RWHP and 270 FWHP (6K rpm) and the same-ish 255 ft.lbs or 350 Nm torque at a bit over 4K rpm at 14.5 psi:




Driving onto the mobile dyno:
http://www.youtube.com/watch?v=kOYaWh5hFSk
Dynorun itself:
http://www.youtube.com/watch?v=xSoyPv_QhNo

RWHP:

Flywheel hp and torque:


It was a beautifull morning and the engine ran great, but I think it may not have gotten the right amount of fresh air because of a closed deck lid and a mediocre Jamex air filter (not the big K&N one I had before).
Or the turbo is just not making enough air (too small). Next time with the proper K&N and an open deck lid on 14th June, lets see if it makes a difference
Reply With Quote
  #47
Old May 23rd 2009, 17:39
Sandeep's Avatar
Sandeep Sandeep is offline
Administrator

Join Date: Aug 2002
Location: Brampton, Ontario, Canada
Posts: 1,795


Where is the ECU reading reading the MAP from ? Under the throttle butterflies or right at the turbo outlet ? If you are reading right at the turbo outlet, the MAP will be more than under the butterflies on boost because of piping and intercooler losses.

I have the same manifold "box" as you but read my map after the butterfly .. I tried both locations and the map at the turbo was 2psi greater than after the butterfly .... looks like my intercooler/piping loss is 2psi

Still wondering why the HP and TQ are the same as your 2 litre

Sandeep
Reply With Quote
  #48
Old May 23rd 2009, 22:39
petevw's Avatar
petevw petevw is offline
Moderator

Join Date: Jul 2002
Location: toronto, ontario, canada
Posts: 1,348
Same Dyno used for the other 2L run?
__________________
'72 super
'65 bus
'52 split
Reply With Quote
  #49
Old May 24th 2009, 01:39
Humble's Avatar
Humble Humble is offline
Registered User

Join Date: Jan 2003
Location: Boulder Creek, CA
Posts: 758
Don't be too down about the numbers until you do a little more digging. Were you datalogging the runs at all? Was there a compression change between the 2 engines? I'd leave the decklid on for dyno runs since it will give a more accurate "street" reading. I'm not sure that you're maxing the turbo yet even with a 2.2, I'd look at the cam, rockers and valves for lost hp.

Looks and sounds great in the video though, it sounds like it wants to keep going when you shut it down.
Reply With Quote
  #50
Old May 24th 2009, 08:11
NO_H2O's Avatar
NO_H2O NO_H2O is offline
Administrator

Join Date: Aug 2002
Location: Stockbridge, GA.
Posts: 2,810
Looks and sounds great. I'm sure with some tuning you will find some power. I know on our 1.9 turbo project, like Sandeep, we found that taking the MAP/boost control sample downstream of the throttle plate made a big difference in the boost we could make. We hope to get back to tuning that combo more this summer. Datalogging will be key to ringing it out. Keep at it.
__________________
NO_H2O
72 1302 Smack Black GL
73 Bus (2L CIS Powered)
66 Beetle, 73 Standard Beetle
72 Pinzgauer 710M
Volksport Kafer Gruppe
Reply With Quote
  #51
Old May 24th 2009, 11:39
Wally's Avatar
Wally Wally is offline
Registered User

Join Date: Nov 2002
Location: The Netherlands
Posts: 2,552
Quote:
Originally Posted by Sandeep View Post
Where is the ECU reading reading the MAP from ? Under the throttle butterflies or right at the turbo outlet ?
Sandeep
It reads from under the 4 butterflies of the TB's

Ah, well, the 1/4 mile drag today went VERY well. Clutch holded out with the street tires, but with the slicks, it was too much and you could smell it (again).
I managed a 12.589/111 mph with the street tires and a 12.184 (no trap speed recorded) with the drag slicks. I am very happy with that
Especially as I was the fastest car of today (40 cars, 30 watercooled)
Had lots of fun today. Hopefully the guys made some pics I will link to later.
Reply With Quote
  #52
Old May 24th 2009, 14:07
Wally's Avatar
Wally Wally is offline
Registered User

Join Date: Nov 2002
Location: The Netherlands
Posts: 2,552







My new rear window decall especially made for the large number of Civic participants
Reply With Quote
  #53
Old May 24th 2009, 18:27
Steve C's Avatar
Steve C Steve C is offline
Registered User

Join Date: Sep 2002
Location: Sydney, Australia
Posts: 1,773
Hi Wally

Does the dyno have a "shootout mode"? Most dyno events use that so that you can compare apples with apples.

Some dyno queens get the operator to alter barometric pressure reading in shootout mode, a lower barometric pressure put in at higher barometric location will give a false high reading, the dyno makes a correction for higher altitude.

Maybe you can see this on your old dyno sheets and compare?

Steve
__________________
STI powered 1303 in the works.
Reply With Quote
  #54
Old May 26th 2009, 16:40
Wally's Avatar
Wally Wally is offline
Registered User

Join Date: Nov 2002
Location: The Netherlands
Posts: 2,552
Thanks for thinking with me Steve!

Here's a vid of the first run still with the street tires (12.5):

http://www.youtube.com/watch?v=FvEH8...e=channel_page
Reply With Quote
  #55
Old May 26th 2009, 18:22
Steve C's Avatar
Steve C Steve C is offline
Registered User

Join Date: Sep 2002
Location: Sydney, Australia
Posts: 1,773
Hi Wally

That run looks quicker than 12.5.

Love your VTEC...THIS sticker, saw one on a WRX the other day, fear no Evo.

Steve
__________________
STI powered 1303 in the works.
Reply With Quote
  #56
Old May 27th 2009, 04:51
blitzvw's Avatar
blitzvw blitzvw is offline
Registered User

Join Date: Jul 2008
Location: Pretoria, South Africa
Posts: 53
Undoubtedly the nicest GermanLook car that I have ever seen!
__________________
Blitzem with Type 4 power
Reply With Quote
  #57
Old May 28th 2009, 17:43
Wally's Avatar
Wally Wally is offline
Registered User

Join Date: Nov 2002
Location: The Netherlands
Posts: 2,552
Quote:
Originally Posted by Steve C View Post
Hi Wally

That run looks quicker than 12.5.

Love your VTEC...THIS sticker, saw one on a WRX the other day, fear no Evo.

Steve
Thanks! Here's the same run from another angle:
http://www.youtube.com/watch?v=Rg4p2...eature=channel
I had WAY too much fun there
Now that I have some things fixed (you learn every time your out running it)...can't wait to get to it again

New 6-puck:
Reply With Quote
  #58
Old May 29th 2009, 01:01
NO_H2O's Avatar
NO_H2O NO_H2O is offline
Administrator

Join Date: Aug 2002
Location: Stockbridge, GA.
Posts: 2,810
Great video. thanks. Keep us updated.
__________________
NO_H2O
72 1302 Smack Black GL
73 Bus (2L CIS Powered)
66 Beetle, 73 Standard Beetle
72 Pinzgauer 710M
Volksport Kafer Gruppe
Reply With Quote
  #59
Old May 29th 2009, 01:21
Steve C's Avatar
Steve C Steve C is offline
Registered User

Join Date: Sep 2002
Location: Sydney, Australia
Posts: 1,773
Hi Wally

Very impressive. You don't have much room to stop at the end of the track, lucky your car is a German look and not a Cal look.

Steve
__________________
STI powered 1303 in the works.
Reply With Quote
  #60
Old May 29th 2009, 13:38
kuleinc's Avatar
kuleinc kuleinc is offline
Registered User

Join Date: Sep 2008
Location: East Bay
Posts: 58
omg, I almost fell out of the chair there... LOL My brother is building a cal look, and I'm building a GL, so true...
